www.calidaddimensional.com STRAIGHT EDGES

Steel straight edges for mounting

I‑shaped construction with wide and extra wide measuring faces for application of spirit levels.
 Length: 500 - 3000 mm.
 Flatness of the measuring faces

according DIN 874.
 Delivery with a manufacturer measuring report.

776.638

With wide measuring faces

Dimensions/mm Weight/kg I tem No. Price MXN Item No. Price MXN

DIN 874/0 D IN 874/1
1000 x 100 x 30 5.0 7 76.631 776.645
1500 x 100 x 30 7.5 776.632 1 7 76.646 1
2000 x 120 x 40 15.0 776.633 1 7 76.647 1
2500 x 120 x 40 19.0 776.634 1 7 76.648 1
3000 x 140 x 40 26.0 776.635 1 776.649 1

1 Delivery ex Groningen, Netherlands. Excluding required shipping box.

With extra wide measuring faces

Dimensions/mm Weight/kg I tem No. Price MXN I tem No. Price MXN

DIN 874/0 D IN 874/1 C09.310.Calidad.20250912
500 x 80 x 40 2.0 7 76.636 776.650
750 x 80 x 40 3.5 7 76.637 776.651
1000 x 160 x 50 12.0 776.638 776.652
1500 x 160 x 50 18.0 7 76.639 1 776.653 1
2000 x 160 x 50 24.0 776.640 1 776.654 1
2500 x 160 x 50 30.0 776.641 1 776.655 1
3000 x 180 x 60 45.5 7 76.642 1 776.656 1

1 Delivery ex Groningen, Netherlands. Excluding required shipping box.

210
