Precision vises
Hardened precision vises for accurate measurements and machine operations.
Accuracy (parallelism, flatness and Precision and universal sine vises
squareness): Stable and accurate to fix in each angle
≤ 100 mm jaw opening = 0.005 mm,
> 100 mm jaw opening = 0.005 mm per 100 mm. position (0 to 45°).
Universal precision vise
With horizontally and vertically ground prism With 360° rotatable base.
in the moveable jaw. Accurate degree scale.
Stable and accurate to fix in each angle
position (0 to 45°).
909.734
909.739 909.746
909.749
Item No. Jaw opening Jaw width Jaw depth Length Price 909.752
mm mm mm mm HUF
Precision vises: 50 25 150
909.733 60 75 35 200
909.734 80 100 40 255
909.735 120 125 50 300
909.736 155
909.737 25 25 10 65
909.738 65 50 25 140
909.739 100 75 35 190
909.740 120 100 45 240
909.741 155 125 50 280
Precision sine vises with swivelling front axis: 140
909.742 60 50 25 190
909.743 100 75 35 250
909.744 120 100 45
Precision sine vises with swivelling rear axis: 140
909.745 60 50 25 190
909.746 100 75 35 250
909.747 120 100 45
Universal sine vises: 140 C07.309.HOD.20250410
909.748 60 50 25 200
909.749 90 75 35 250
909.750 120 100 45 300
909.751 155 125 50
Universal precision vise: –
909.752 80 70 30
