www.calidaddimensional.com MAGNIFIERS / PEN MICROSCOPES
Peak head magnifier 2.2x ... 3.3x
Because of the velcro strip, the head magnifier can be used easily. The great advantage of a head mag
nifier is that the user has both hands free for e.g. production and assembly of precision instruments. The
head magnifier is designed in such a way that people who wear glasses can use it as well. With the extra
pair of lenses inside the head magnifier, the magnification can be enhanced from 2.2x to 3.3x.
Clear, broad and 3-dimensional view.
Weight: 100 g.
Item No. Magnification Price
905.318 2.2x / 3.3x
Peak pen microscopes with EIM 25x ... 100x
These pen microscopes have a fixed scale and EIM system. With 905.404
standard microscopes, the magnification is upside down, but
because of the EIM system, this is not the case with
these pen microscopes.
Dimensions: ø 20.7 x 111 mm.
Weight: 25 - 28 g.
Item No. Magnifi- Field of Measuring Graduation Price
cation view ø/mm range/mm mm MXN
905.404 25x 3.50 3.0 0.05
905.405 50x 1.70 1.6 0.02
905.406 75x 1.10 1.0 0.01
905.407 100x 0.86 0.8 0.005
Peak pen microscopes 25x ... 100x
Dimensions: 905.267
ø 12.4 x 127 mm.
Item No. Magnifi- Field of Measuring Graduation Price
Weight: 13 - 16 g. cation view ø/mm range/mm mm MXN
With a fixed scale
(only 905.263/264).
905.267 25x 3.30 ––
905.268 50x 2.00 ––
905.269 75x 1.09 ––
905.266 100x 0.84 ––
With fixed scale: 3.30 3.00 0.05 C13.205.Calidad.20250912
905.263 25x 2.00 1.60 0.02
905.264 50x
