www.calidaddimensional.com MAGNIFIERS
Peak ABC magnifier 3-18x Magnifier on magnetic stand
The ABC magnifier consists of three lenses. Magnification: 2x (ø 90 mm).
Combining the three lenses, seven different Total length: 280 mm.
magnifications are possible. Magnetic force: 600 N.
Magnification: 3x, 6x, 9x, 12x, 14x, 16x and 18x.
Magnification and diameter of the lenses:
lens A: 12x, ø 14 mm,
lens B: 3x, ø 28 mm,
lens C: 6x, ø 20 mm.
Dimensions: 60 x 39 x 24 mm.
Weight: 76 g.
Item No. Description Price Item No. Description Price
905.196 ABC magnifier 3-18x 909.609 Magnifier on
magnetic stand
Peak magnifying glass 2.5 - 5x Peak flexible stand magnifier
This model of the classic magnifying glass This magnifier has a flexible arm which can be
has a lens-in-lens construction. In the big ø 75 mm adjusted freely from a solid and stabilized stand.
lens a smaller ø 20 mm lens has been integrated The lens can be put in many positions for the
which offers extra strong magnification. The big most ergonomic use thus leaving both hands of
lens has a 2.5x magnification, the small lens 5x. the user free.
Dimensions: ø 80 x 170 mm. Dimensions:
Weight: 111 g.
145 x 120 x 485 mm
(maximum height).
Weight: 1.5 kg.
905.279
Item No. Description Price Item No. Magnification Lens Price C13.212.Calidad.20240712
905.214 Magnifying glass 2.5 - 5x ø/mm MXN
905.279 1.7x 115
905.428 2.2x 90
