Drill gauges Twist drill grinding gauges

Gauge in the form of a steel plate with bores For checking twist drills at their top and on
of increasing diameters for determining drill the right value of 120° angle of the twist drill
diameters. point. The maximum drill diameter is 50 mm.
 Increment: 0.1 mm.

836.640 910.372

Item No. Measuring Number Price
range/mm of bores MXN

836.640 0.1 - 10 100

Measuring wedges

Measuring wedges for quick measurements
and checks of slits, key-ways, distances, etc.
 Measuring range: 0.4 - 26 mm.
 Graduation: 0.05, 0.1 or 0.2 mm.
 Laser engraving.

909.537 Universal twist drill grinding gauge, also
909.535 called Y‑gauge. Besides the standard angle
of 120°, this gauge also has a 90° angle for
counter­sink drills, and some special angles for
center drills.

909.536

856.331

856.443

Item No. Measuring Graduation Price
range/mm mm MXN

909.535 0.4 - 6 0.05 Item No. Description Price C12.312.Calidad.20240712
856.331 0.5 - 11 0.1 910.372 Twist drill grinding gauge
909.536 1 - 15 0.1 856.443 Y‑gauge
909.537 2 - 26 0.2
