www.calidaddimensional.com GAUGES / MEASURING WEDGES
Drill gauges Twist drill grinding gauges
Gauge in the form of a steel plate with bores For checking twist drills at their top and on
of increasing diameters for determining drill the right value of 120° angle of the twist drill
diameters. point. The maximum drill diameter is 50 mm.
Increment: 0.1 mm.
Item No. Measuring Number Price
range/mm of bores MXN
910.501 0.5 - 10 96
Measuring wedges 910.372
Measuring wedges for quick measurements Universal twist drill grinding gauge, also
and checks of slits, key-ways, distances, etc. called Y‑gauge. Besides the standard angle
Measuring range: 0.4 - 26 mm. of 120°, this gauge also has a 90° angle for
Graduation: 0.05, 0.1 or 0.2 mm. countersink drills, and some special angles for
Laser engraving. center drills.
909.537
909.535
909.536
856.331
Item No. Measuring Graduation Price 856.443
range/mm mm MXN
909.535 0.4 - 6 0.05 Item No. Description Price C12.312.Calidad.20250912
856.331 0.5 - 11 0.1 910.372 Twist drill grinding gauge
856.332 * 0.5 - 11 0.1 856.443 Y‑gauge
909.536 1 - 15 0.1
909.537 2 - 26 0.2
* Plastic material.
