LMW thread plug and ring gauges (continued)
Hardened steel thread plug gauges (Go + Hardened steel thread plug gauges (Go +
NoGo) and thread ring gauges (Go or NoGo) NoGo) and thread ring gauges (Go or NoGo)
for metric screw thread (ISO) with pitch 0.5. for metric screw thread (ISO) with pitch 1.
Manufactured according ISO 1502 (DIN 13). Manufactured according ISO 1502 (DIN 13).
Indication Price MXN Price MXN Indication Price MXN Price MXN
M... x 0.5 Thread plug Thread ring M... x 1 Thread plug Thread ring
5 8
6 10
8 11
10 12
12 14
14 16
16 18
18 20
20 22
24
25
26
27
28
30
Hardened steel thread plug gauges (Go + Hardened steel thread plug gauges (up to M40:
NoGo) and thread ring gauges (Go or NoGo) Go + NoGo, from M42: Go and NoGo separate)
for metric screw thread (ISO) with pitch 0.75. and thread ring gauges (Go or NoGo) for metric
Manufactured according ISO 1502 (DIN 13). screw thread (ISO) with pitch 1.5. Manufactured
according ISO 1502 (DIN 13).
Indication Price MXN Price MXN Indication Price MXN Price MXN
M... x 0.75 Thread plug Thread ring M... x 1.5 Thread plug Thread ring
6 12 (continued on the next page)
8 14 C12.209.Calidad.20240712
10 16
12 18
14 20
16 22
18 24
20 25
22 26
24 27
26 28
28 30
30
