Thread plug and ring gauges in sets
Sets of thread plug gauges or thread ring gauges for inspection of metric ISO threads.
836.561 For threads M3, M4, M5, M6, M8, M10 and
M12.
Tolerance class:
thread plug gauges: 6H,
thread ring gauges: 6g.
Hardened steel, thread plug gauges with
aluminum grip.
Manufactured according ISO 1502 (DIN 13).
Delivery in a wooden case with a
manufacturer measuring report.
Item No. Thread gauges set Price HUF
836.561 Plug gauges (Go + NoGo)
836.562 836.562 Ring gauges (Go)
836.563 Ring gauges (NoGo)
Plug gauges and setting rings in sets
Hardened steel, plug gauges with aluminum
grip.
Set setting rings manufactured according
DIN 2250 form C.
Set plug gauges manufactured according
DIN 2248/2249.
Delivery in a wooden case with a
manufacturer measuring report.
Item No. Description Price HUF
836.564 Setting rings: ø 4, ø 5, ø 6, ø 8 mm
836.565 Setting rings: ø 10, ø 12, ø 16, ø 20, ø 25 mm
836.566 Plug gauges (Go + NoGo)
H7: 3, 4, 5, 6, 8, 10, 12 mm
Thread jaw gauges
Jaw‑shaped gauge for inspection of external
screw thread. For correct use, a setting thread
plug gauge is needed. These can be purchased
separately.
Setting thread plug gauge Available on request. C12.212.HOD.20250702
