www.hod-industrial.hu CLINOMETERS

Digital clinometer

Instrument for easy measurement of angles, flatness and squareness. All four sides are measuring
faces. The measuring value is displayed upright at any time.

 Measuring range: 4 x 90°.  Sound signal at stable value.
 Resolution: 0.05°.  °, mm/m, %, inch/ft conversion.
 Accuracy 0 - 10°: ± 0.1°,  Reference plane function.
 Measuring faces bottom- and upper-side with
10 - 80°: ± 0.2°,
80 - 90°: ± 0.1°. V‑groove.
 Repeatability: 0.1°.  With magnetic base (2 magnets).
 ABS/INC switchable.  Protection: IP65.
 Large, easy-to-read LCD display.  Dimensions l x w x h: 151 x 32 x 60 mm.
 Automatic switch-off.  Delivery in a soft case.
 Hold function.  Power supply: 2 batteries type AAA.
 Blue backlight.

Item No. Description Price HUF
909.504 With V‑grooves

and magnetic base
Option:
497.914 Battery type AAA

(2 needed)

Digital clinometer

Instrument for easy measurement of inclination. Equipped with a horizontal and vertical vial. The
measuring value is displayed upright at any time.

 Measuring range: 4 x 90°.  ° and % conversion.
 Resolution: 0.1°.  Large, easy-to-read LCD display.
 Accuracy 0 - 10°: ± 0.1°,  On/off switch.
 Hold function.
10 - 80°: ± 0.2°,  Sound signal at: 0°, 45°, 90°.
80 - 90°: ± 0.1°.  Measuring face on the bottom- and upper-side.
 Length: 600 mm.
 Delivery in a carrying bag.
 Power supply: 2 batteries type AAA.

Item No. Description Price HUF 906.477 C08.318.HOD.20250410
906.477 Clinometer 225
Option:
497.914 Battery type AAA

(2 needed)
