www.hod-industrial.hu PARALLELS

Steel parallel blocks

Parallels to position and layout workpieces in e.g. clamping jaws for drilling, grinding, milling and
measuring. The workpieces and assemblies can easily be set up to the desired working height.

 Parallelism of the two measuring faces:  Ground in matched pairs.
± 0.005 mm.  Produced of a high-grade steel alloy.
 Delivery in a wooden case with a declaration
 Size deviation (height): ± 0.01 mm.
 Hardness: 55 HRC. of conformity.

Item No. Length Price Width Height
mm HUF mm mm

906.996 Set of 12 pairs: 10
909.800 100 14 - 16 - 18 - 20 - 22 - 24 -
(Only available in sets.) 909.804 125 26 - 28 - 30 - 32 - 35 - 40
906.995 150 10
Set of 14 pairs: 14 - 16 - 18 - 20 - 22 - 24 -
909.802 100 8 26 - 28 - 30 - 32 - 35 - 40 -
909.805 125 10 45 - 50
906.996 150 12
Set of 24 pairs: 14 11 - 16 - 21 - 26 - 31 - 36
909.803 100 13 - 18 - 23 - 28 - 33 - 38
909.806 125 15 - 20 - 25 - 30 - 35 - 40
906.997 150 17 - 22 - 27 - 32 - 37 - 42

Adjustable parallel set

Set of 6 adjustable parallels. The parallels consist of 2 precisely ground tapered parts dovetailed
together to ensure easy setting. These allow you to quickly clamp a workpiece in the correct position
on a workbench, set a measuring instrument or check the internal dimensions of two parallel surfaces.

Parallel Measuring Measuring face
A range/mm length/mm
B
C 9.5 - 12.7 45 Item No. Size/mm Price HUF C09.311.HOD.20250410
D 12.7 - 17.5 54 910.400 9.5 - 57.1 mm
E 17.5 - 23.8 69
F 23.8 - 33.3 90
33.3 - 44.5 107
44.5 - 57.1 117
