www.calidaddimensional.com VIBRATION TESTERS / SOUND LEVEL METERS
Digital vibration tester
Instrument with external sensor for quick checking of unbalance, misalignment, bearings and gears.
For measuring velocity, acceleration, displacement and frequency.
Measuring range
Velocity: 0.01 - 99.99 mm/s,
100.0 - 400.0 mm/s
(RMS, at frequency 10 Hz - 1 kHz).
Acceleration: 0.1 - 400 m/s2 (peak value,
at frequency 10 Hz - 1 kHz or 10 Hz - 10 kHz).
Displacement: 0.001 - 4.0 mm
(P‑P, at frequency 10 Hz - 1 kHz).
Frequency: 0.1 - 20 kHz.
Further specifications Item No. Description Price
Accuracy: ± 5% + 2 digits. 909.065 Vibration tester
mm/inch conversion. Options:
RS232C data output. 497.914 Spare battery type AAA
Operating temperature: 0 to 50°C.
Dimensions: 125 x 62 x 31 mm. (4 needed)
Weight: 255 g. 909.074 RS232C cable and software
Delivery in a plastic case with a manufacturer
measuring report, incl. magnet and
2 attachments.
Power supply: 4 batteries type AAA.
Digital sound level meter Power supply: 1 battery type PP3 (9 V).
Instrument for measuring the sound level.
Measuring range: 30 - 130 dB.
Resolution: 0.1 dB.
Accuracy: ± 1.5 dB.
Frequency weighting: A and C.
Frequency range: 31.5 Hz - 8.5 kHz.
Measuring frequency: 2 times per second.
Time weighting: fast/slow.
The current measured value within the range
of 50 dB is displayed graphically (adjustable).
Over range indication.
Automatic switch-off.
Max function.
Dimensions: 207 x 70 x 29 mm.
Weight: 178 g.
Delivery in a plastic case.
Item No. Measuring range/dB Price
909.131 30 - 130 C18.311.Calidad.20240712
Option:
495.161 Spare battery type PP3 (9 V)
