Page 217 - Schut Catalog

www.calidaddimensional.com PROTRACTORS

Universal digital bevel protractor

This stainless steel, digital bevel protractor is available with blades from 150 to 1000 mm. The
blades and all the measuring faces are hardened.

 Measuring range: ± 360°.  Control with 5 keys for several functions.
 Resolution: 1', or decimal 0.01°.  Fine adjustment.
 Accuracy: ± 2'.  Delivery in a wooden case with 150 mm
 Repeatability: 1'.
 Indication switchable from degrees and blade.
 Power supply: 1 battery type CR2032.
minutes to decimal degrees.  Also available in heavy duty type (855.805).
 + and - direction reversible.
 Per 90° adjustable.
 Data output, Mitutoyo Digimatic compatible.
 On/off switch.
 Reset/preset/hold functions.

855.812 855.813 855.815

855.805

Item No. Description Price Single blades
855.820 Bevel protractor
Options: Item No. Blade length/mm Price
495.157 Battery type CR2032
855.812 Acute angle attachment 909.380 150 C08.203.Calidad.20250912
855.813 Stand 909.381 200
855.815 Height Gauge Holder 909.382 300
905.409 Data cable 2 m 909.383 500
855.827 1000

217
