Plug gauges H7
Manufactured according DIN EN ISO 1938. Available from 1 - 100 mm with Go and NoGo on one
handle.
DIN 7162 and 7164.
H7 fit size in hardened steel.
With serial number.
Delivery with a manufacturer measuring report.
Individual plug gauges delivered in a plastic
tube. Set delivered in a plastic case.
Including wear allowance at the Go end.
Wear allowance
New gauges are supplemented with a wear
allowance on the Go end: z (plus) for plug gauges.
Accordingly, the size indicated on the handle is not
similar to the measured value of the new Go end.
Item No. Size H7 Price Item No. Size H7 Price Item No. Size H7 Price
mm MXN mm MXN mm MXN
Price
911.000 1 911.023 19 911.047 47
911.001 1.5 911.024 20 911.048 48
911.002 2 911.025 21 911.049 50
911.003 2.5 911.026 22 911.050 52
911.004 3 911.027 23 911.051 55
911.005 3.5 911.028 24 911.052 58
911.006 4 911.029 25 911.053 60
911.007 4.5 911.030 26 911.054 62
911.008 5 911.031 27 911.055 65
911.009 5.5 911.032 28 911.056 68
911.010 6 911.033 30 911.057 70
911.011 7 911.034 32 911.058 72
911.012 8 911.035 33 911.059 75
911.013 9 911.036 34 911.060 78
911.014 10 911.037 35 911.061 80
911.015 11 911.038 36 911.062 82
911.016 12 911.039 37 911.063 85
911.017 13 911.040 38 911.064 88
911.018 14 911.041 40 911.065 90
911.019 15 911.042 42 911.066 92
911.020 16 911.043 44 911.067 95
911.021 17 911.044 45 911.068 98
911.022 18 911.045 46 911.069 100
Set plug gauges
Item No. Description C12.307.Calidad.20240712
911.157 Plug gauges (Go + NoGo) H7: 3, 4, 5, 6, 8, 10, 12 mm
