Clamping bush                               6 0.7                                             Inserts

          12                                                                                  Many inserts with thread
                                                                                            M2.5 are available. See the dial
ø10h8                                                                                       indicator accessories section for
                    ø8H7                                                                    more information.
                                                                               ø1.5
                                                                                   M4         Retraction levers
VKE                                         VKD
                                                                                              Universal retraction levers, bottom or top
     780.398                                     Price                                      mounted, compatible with a wide range of
                                                                                            probes and dial indicators. You can find various
Item No. Description                                                                        models in the dial indicator accessories section.

780.398 Clamping bush VKE
780.397 Clamping screw VKD

Clamping bush

                              7 11          17.5
                                                       25.3

Item No. Description                                                 ø8H7                     Retraction device DZ801
906.497 Clamping bush                                                ø10h7
                                                                                              Pneumatic
                                                                   Price                    retraction device
                                                                                            for Magnescale and
  Probe holder                                                                              TESA gauges, with
                                                                                            1 meter hose and air
  Probe holder for for surfacemounting.                                                     tube connector.
	 Clamping shaft: ø 8 mm.
	 For attaching with M4 bolts.                                                             Item No. Description       Price
	 Material: anodized aluminum.                                                             344.465 Retraction device

                                                             =30=

                       ø8 H7                ø4.5 THRU (2x)                                    Clamp collar with dovetail

                      12 8=20=              ø4.5 THRU                                         For clamping TESA GT31 probes and e.g.
                                                   6=10=                                    lever type dial indicators.
                                                       40                                   	 Fastening points:

                                                                                              ø 5.6 mm, ø 9.5 mm
                                                                                              and with dovetail.

Item No. Description          M4x0.7 - 8 DEEP (2x)                                          Item No. Description       Price                   C05.316.Calidad.20240712
993.054 Probe holder                                                                        780.208 Clamp collar
                                      Price
