DIAL INDICATORS www.calidaddimensional.com
Digital dial indicators
Universal digital indicators with both digital and digital-analog display of the measuring value, and
can also be rotated over 340° to ensure easy read-out in all positions.
Measuring range: 0 - 12.7 mm. Clamping stem: ø 8 mm.
Resolution: 0.001 mm. Dial diameter: 61 mm.
Analog resolution: Dial 340° rotatable.
Reversible measuring direction.
0.001 / 0.002 / 0.01 / 0.02 / 0.05 mm. Adjustable tolerance limits.
mm/inch conversion. Protection: IP54.
ABS/INC switchable. Delivery in a plastic case.
On/off switch. Power supply: 1 battery
Automatic switch-off.
Reset/preset. type CR2032.
Item No. Measuring Accuracy Price
range/mm mm MXN
907.879 0 - 12.7 ± 0.01
907.878 0 - 12.7 ± 0.005
Option: 907.879
495.157 Spare battery type CR2032
Clamping shaft: ø 6 mm.
Digital indicators Clamping stem: ø 8 mm.
Insert thread: M2.5.
Measuring range: 0 - 100 mm. Power supply: 1 battery type V357.
Resolution: 0.01 mm.
mm/inch conversion.
On/off switch.
Reset.
910.312
Item No. Measuring Measuring Total Price
range/mm force/N length/mm MXN
910.311 0 - 50 < 2.5 148 910.312 C05.343.Calidad.20240712
910.312 0 - 100 < 3.2 330 Calidad 2023/2024-DeMeet-D
Option:
836.535 Spare battery type V357
