Schut Geometrical Metrology CLINOMETERS
TESA Clinobevel 1‑USB digital clinometer
The TESA Clinobevel 1‑USB is a compact and universal clinometer with four measuring faces and
a reinforced aluminum housing, resistant to workshop conditions. For a higher accuracy 21 correction
values can be stored. The software can perform calculations with two instruments and export
automatic reports.
Measuring range: ± 45°. USB
Resolution: 0.025 mm/m (5").
Accuracy: 2' + 1 sd. Calculations with
USB data output. two instruments.
Read-out after approx. 1 s when idle.
Dimensions: 100 x 75 x 30 mm.
Protection: IP65.
DIN 2276.
Delivery in a plastic carrying case with a
manufacturer measuring report, batteries,
USB cable (1.8 m), software and user
manual.
Power supply: 4 batteries type AA.
Read-out angles: Item No. Type/description Price EUR
• degrees (2 or 4 decimals)
• degrees and minutes 781.545 Clinobevel 1‑USB 2,178.00
Read-out inclination: 783.624 * Clinobevel 1‑USB 1,874.00
• mm/m (2 decimals)
• inch/10 inch or inch/12 inch (4 decimals) Options: 0.70
• mm or inch/basis length (comparative mode) 495.111 Spare battery type AA (4 needed) 333.00
• milliradians (whole or 2 decimals) 783.625 USB cable (1.8 m)
• gon (2 decimals)
* Without USB cable and software.
TESA Clinobevel 3 digital clinometer
The TESA Clinobevel 3 is a very accurate, robust and easy to use clinometer in cast iron or
aluminum housing. Measuring values can be easily read from the clear LCD screen. Two sides are
fitted with (optionally magnetic) measuring faces with a fine ground V-groove.
There are two models available:
– Measuring range: +/- 60° or +/- 1° (only available in the cast iron version),
– Resolution: 0,025 mm/m (60° model), 0,001 mm/m (1° model).
MicroSD card USB
Bluetooth MicroASpDpcard USB
DetailedBluetooth App
Especially suitable for calibration and measuring of straightness, flatness and information
squareness of high accuracy measuring and processing machines. For measurements
in hard to reach places you can link the Clinobevel via bluetooth to the Android app available C08.211.EN.20240206
and the readout will be displayed on your phone or tablet.
