CLINOMETERS / ALIGNMENT TOOLS Schut for Precision

Digital clinometer

Instrument for easy measurement of inclination. Equipped with a horizontal and vertical vial. The
measuring value is displayed upright at any time.

 Measuring range: 4 x 90°.  ° and % conversion.
 Resolution: 0.1°.  Large, easy-to-read LCD display.
 Accuracy 0 - 10°: ± 0.1°,  On/off switch.
 Hold function.
10 - 80°: ± 0.2°,  Sound signal at: 0°, 45°, 90°.
80 - 90°: ± 0.1°.  Measuring face on the bottom- and upper-side.
 Length: 600 mm.
 Delivery in a carrying bag.
 Power supply: 2 batteries type AAA.

Item No. Description Price EUR 906.477
906.477 Clinometer 77.00
Option:
497.914 Spare battery type AAA 0.80

(2 needed)

Laser alignment tool

With this alignment tool you can precisely, quickly and easily project vertical, horizontal and
crossed laserlines. Within a range of ± 4° minor inclination errors are automatically compensated by
means of the integrated spirit level, to level the projected horizontal line.

 Range: up to 30 m (dependent on the lighting  Intake internal thread on the bottom-side:
conditions). UNC 1/4"-20, thread depth: 8 mm.

 Self-levelling range: 4°.  Delivery in a soft case including a plastic
 Horizontal and vertical accuracy: mounting bracket with 2 strong magnets.

± 4.5 mm / 15 m.  Power supply: 2 batteries type AA.
 Laser: 510 - 530 nm, class 2 conform to

IEC 60825‑1/2007.
 Lock function for projecting at an angle and

transport protection.
 On/off switch.
 Dimensions: 74 x 64 x 75 mm.
 Weight: 270 g.
 Protection: IP54.

Item No. Description Price EUR C08.314.EN.20240206
910.369 Alignment tool 68.00
Option:
495.111 Spare battery type AA 0.70

(2 needed)

© 2024, Schut Geometrische Meettechniek bv 346 Measuring instruments and systems 2023/2024
