DIAL INDICATORS Schut for Precision
Mitutoyo Absolute Digimatic dial indicators ID‑C (continued)
Multifunctional dial indicators with special functions for various applications. Which includes
a version with min/max/P-P function, a version especially made for internal measurements, and a
version with built-in calculation function. The results, for example, inside and outside diameter,
groove width, bore diameter, and curve radius, are determined based on the spindle displacement x;
formula: Ax + B + Cx‑1. The coefficients A, B and C can be set and the calculations are processed and
displayed in real-time.
Measuring range: 0 - 50.8 mm. Model for internal measurements (543.310)
Resolution: 0.0002 to 1 mm, switchable. Spindle movement is displayed graphically
ABS/INC switchable (except 543.310).
LCD 330° rotatable. (determination of the reversal point).
Digimatic data output. Storage for 3 preset values (for example size
On/off switch.
Reset/preset. setting ring).
Hold function. Bridges for dial indicators with calculation
Max. measuring speed: unlimited. function.
Clamping stem: ø 8 mm.
Adjustable tolerance limits. Especially made for dial indicators with
Protection: IP42. calculation function. Combined with these dial
Delivery with a manufacturer measuring report. indicators, these bridges can provide a multitude
Power supply: 1 battery type CR2032. of solutions. For these bridges, see bridges
elsewhere in the catalog.
Model with min/max/P‑P function (543.300)
Key lock function.
Item No. Measuring Accuracy Measuring Price
range/mm mm force/N EUR
With min/max/P‑P function: 527.00
543.300 0 - 12.7 ± 0.003 ≤ 1.5
For internal measurements: 580.00
543.310 0 - 12.7 ± 0.003 ≤ 1.5
With calculation function: 648.00 543.300
543.340 0 - 12.7 ± 0.003 ≤ 1.5 729.00
543.590 0 - 25.4 ± 0.003 ≤ 1.8 874.00
543.595 0 - 50.8 ± 0.006 ≤ 2.3
Options: 0.50 543.340 C05.346.EN.20260702
495.157 Battery type CR2032 39.00 543.310
905.338 Digimatic signal cable, 1 m 47.00
905.409 Digimatic signal cable, 2 m 128.00
106.384 USB Input Tool Direct cable, 2 m 98.00
102.795 U-WAVE adapter cable 8.00
210.198 Retraction lever 83.80
211.301 Cable retraction device 16.00
101.040 Back plate with lug 351.00
106.543 USB-ITPAK V3.0 189.00
197.00
Full version software 380.00
102.670 U-WAVE Transmitter mounting plate
264.623 U-WAVE fit transmitter
264.627 U-WAVE fit Bluetooth transmitter
102.810 U-WAVE receiver and software
