Screw thread micrometers (continued)

Measuring inserts for screw thread micrometers with clamping shaft ø 5 mm.

Item No. Threads per inch Price CZK

Measuring inserts for Whitworth threads,
55° flank angle, per pair:
906.730 60 - 48
906.731 48 - 40
906.732 40 - 32
906.725

906.733 32 - 24
906.734 24 - 18
906.735 18 - 14
906.736 14 - 10
906.737 10 - 7.0
906.738 7.0 - 4.5
906.739 4.5 - 3.5

906.740 Set 60 - 3.5

Item No. Pitch/mm Price CZK Item No. Threads per inch Price CZK

Measuring inserts for metric threads, Measuring inserts for UN, UNC and UNF
60° flank angle, per pair: threads, 60° flank angle, per pair:
906.720 0.4 - 0.5 906.741 64 - 48
906.721 0.6 - 0.9 906.742 44 - 28
906.722 1.0 - 1.75 906.743 24 - 14
906.723 2.0 - 3.0 906.744 13 - 9
906.724 3.5 - 5.0 906.745 8 - 5
906.725 5.5 - 7.0 906.746 4.5 - 3.5

906.726 Set 0.4 - 7.0 906.747 Set 64 - 3.5

909.305

Item No. Length/mm Price CZK Item No. Length/mm Price CZK

Hardened steel setting standards for threads Hardened steel setting standards for threads
with 60° flank angle: with 55° flank angle:
909.304 25 909.312 25
909.305 50 909.313 50
909.306 75 909.314 75
909.307 100 909.315 100
909.308 125 909.316 125
909.309 150 909.317 150 C03.241.WHP-ENG.20250410
909.310 175 909.318 175
909.311 200 909.319 200
