www.whp.cz DEPTH CALIPERS

Digital depth calipers

Digital depth calipers with interchangeable inserts such as a (double) hook, disc attachment and a
measuring pin. Additionally, there is an adapter from M3 thread to M2.5 thread. This adapter allows
the use of inserts from dial indicators. For these inserts, see dial indicator accessories elsewhere in
this catalog.

 Measuring range: 0 - 500 mm.  Interchangeable measuring inserts included:
 Resolution: 0.01 mm. 3 measuring inserts: a (double) hook,
 Accuracy: ± 0.03 mm. a disk attachment ø 30 mm, d = 3 mm,
 mm/inch conversion. a measuring pin ø 3 mm, l = 8 mm,
 ABS/INC switchable. an adapter ø 5 mm, l = 10 mm, from M3
 On/off switch. thread to M2.5 thread,
 Automatic switch-off. 4 measuring inserts M2.5: 2 ball probes,
 Reset/preset. knife-edged probe, needle-shaped probe.
 Hold function.
 Tolerance function.  Delivery in a wooden box.
 Locking screw.  Power supply: 1 battery type V357.

15 x 6 ø3 ø5
M2.5-6g M2.5-6g
5 5

12 20
13

ON/OFF ZERO ø5 ø1.5

HOLD TOL 910.497 M2.5-6g ø5
ABS SET 5 M2.5-6g
mm/in M3 8 5
5 ø5
10 5.5 3.2 ø5 20° 16

M2.5 0.6

M3 Adapter Moveable bridges
160

Item No. Measuring Price Item No. Measuring face Height Price
910.497 range/mm CZK l x w/mm h/mm CZK
910.498
0 - 300 910.499 300 x 15 25
0 - 500 910.500 500 x 15 25

Option:
836.535 Battery type V357
3 l 6 mm w
3
6.8 6.8 6.8 ø30 ø3
28.6 3
3ABS SETABS SETABS SET
ABS SET 8hmm/inmm/inmm/in
mm/in
