www.whp.cz GAUGE BLOCKS
Long gauge blocks from 125 mm
Long steel gauge blocks with an excellent price-performance ratio. These steel gauge blocks are
available in the accuracy classes 0, 1 and 2 of ISO 3650. All gauge blocks have two coupling holes on
both ends so that they can be coupled by means of a toggle clamp.
Hardness: 63 - 65 HRC. ISO 3650.
Expansion coefficient: (11.5 ± 1)·10‑6/°C. Delivery in wooden case with a manufacturer
Cross-section: 35 x 9 mm.
measuring report.
907.707
907.741
Size/mm Item No. Price CZK Item No. Price CZK Item No. Price CZK
125 ISO 3650/2: ISO 3650/1: ISO 3650/0:
150 907.728 907.715 907.702
175 907.729 907.716 907.703
200 907.730 907.717 907.704
250 907.731 907.718 907.705
300 907.732 907.719 907.706
400 907.733 907.720 907.707
500 907.734 907.721 907.708
600 907.735 907.722 907.709
700 907.736 907.723 907.710
800 907.737 907.724 907.711
900 907.738 907.725 907.712
1000 907.739 907.726 907.713
907.740 907.727 907.714
Gauge block set consisting of 125, 150, 175, 200, 250, 300, 400 and 500 mm:
907.743 907.742 907.741 C11.301.WHP-ENG.20250410
Gauge block set consisting of 600, 700, 800, 900 and 1000 mm:
907.746 907.745 907.744
