www.hod-industrial.hu DF FIXTURE SYSTEM

DF product fixture system (continued)

DF is available in separate components and in three basic sets, in black or silver finishing. Basic
set I is composed for the DeMeet‑220, basic set II for the DeMeet‑400 (Y‑axis) and basic set III for
the DeMeet‑400 (X‑axis) and the DeMeet‑404/443 (X‑ and Y‑axis).

Item No. Description Price HUF
717.057 Basic set I DeMeet‑220 Black
717.088 Basic set I DeMeet‑220 Silver
717.095 Basic set II DeMeet‑400Y Black
717.096 Basic set II DeMeet‑400Y Silver
717.058 Basic set III DeMeet‑400X/4xxXY Black
717.089 Basic set III DeMeet‑400X/4xxXY Silver

Item No. Description Number Basic set
I II III
black silver
8 • • •
717.029 717.073 Mounting block perpendicular 4 • • •
717.030 717.074 One point anvil 2 • • •
717.031 717.075 One point anvil long 3 • • •
717.036 717.077 Mounting block for spring shaft 2 • • •
717.040 717.081 V‑block 120° 2 • • •
717.042 717.083 V‑block 90° 4 • •
717.033 717.043 Mounting block side pattern 16 4 • •
717.028 717.072 Mounting block end pattern 16 4 •
717.034 717.050 Mounting block side pattern 25 4 •
717.035 717.056 Mounting block end pattern 25 2 •
717.015 717.059 Bar 56 mm 2 •
717.016 717.060 Bar 88 mm 2 •
717.097 717.098 Bar 110 mm 2 •
717.017 717.061 Bar 120 mm 2 •
717.018 717.062 Bar 160 mm 2 •
717.022 717.066 Bar 246 mm 2 • •
717.024 717.068 Bar 310 mm 2 •
717.026 717.070 Bar 344 mm 2 •
717.025 717.069 Bar 460 mm
4 • •
717.044 Screw and adapter pattern 16 8 • •
380.301 Distance tube with stop pattern 16 8 •
380.304 Distance tube with stop pattern 25 8 • •
993.539 Screw M4 x 20 stainless steel 8 •
995.087 Screw M6 x 25 stainless steel 3 • • •
717.000 Shaft 60 mm for clamping spring 2 • • •
717.004 Shaft 50 mm for clamping spring 3 • • •
717.010 Clamping spring short 2 • • •
717.011 Clamping spring long 1 • • •
991.158 Hex screwdriver 2 mm 1 • •
991.160 Hex screwdriver 3 mm 1 •
991.161 Hex screwdriver 4 mm 1 • •
717.008 Screw mounting tool 1 • •
851.888 Case for DF basic sets I and II 1 •
851.899 Case for DF basic set III

Item No. Description Price HUF
991.158 Hex screwdriver 2 mm
991.160 Hex screwdriver 3 mm 991.276 C26.302.HOD.20250410
991.161 Hex screwdriver 4 mm
991.276 Adjustable torque hex screwdriver

2 mm with range 0.1 - 0.6 Nm
