www.hod-industrial.hu STEREO MICROSCOPE ACCESSORIES

SSM stereo microscope accessories

USB microscope cameras Item No. Description Price HUF
For viewing and saving images. They fit in
Pairs of eyepieces for SSM‑2/3/5/10/20:
the ocular (ø 30 mm) of an SSM microscope 909.050 M = 5x
and/or the adapter bushing (ø 23 mm) of the 909.051 M = 10x
models SSM‑3E/3EC2. 909.052 M = 15x
 Field of view: see table. 909.053 M = 20x
 Resolution: 1.3 Mpx or 5 Mpx.
 Suitable for Windows and Mac OS X. Pairs of eyepieces for SSM‑E:
 Measuring of distances, radii and angles. 909.055 M = 10x
Auxiliary lenses 909.057 M = 20x

The magnification can be adjusted to your Eyepieces with crosshair for SSM‑E:
application even more with an optional auxiliary 909.095 M = 10x (per piece)
lens. Note concerning stereo microscopes with 909.096 M = 20x (per piece)
a fixed stand: aux­iliary lens 0.5x is not suitable,
and with auxiliary Auxiliary lenses (for SSM‑10/20/E):
lenses 1.5x and 2x 909.018 M = 0.5x
focus­ing on the stage 909.019 M = 0.75x
plate is not possible 909.020 M = 1.5x
(the product needs 909.021 M = 2x
to be positioned
higher). USB microscope cameras:
774.296 1.3 Mpx, ø 23 / 30/ 30.5 mm
909.018 - 021 774.243 5 Mpx, ø 23 / 30/ 30.5 mm

Magnification Microscope magnification / Field of view/mm
objective Eyepiece 5x Eyepiece 10x Eyepiece 15x Eyepiece 20x

Stereo microscope SSM‑2:

2x 10x / ø 10.0 20x / ø 10.0 30x / ø 7.0 40x / ø 5.0

Pairs of eyepieces Stereo zoom microscope SSM‑3/5:

1x 5x / ø 20.0 10x / ø 20.0 15x / ø 15.0 20x / ø 10.0

2x 10x / ø 10.0 20x / ø 10.0 30x / ø 7.0 40x / ø 5.0

3x 15x / ø 7.0 30x / ø 7.0 45x / ø 5.0 60x / ø 3.5

4x 20x / ø 5.0 40x / ø 5.0 60x / ø 3.5 80x / ø 2.5

Stereo zoom microscope SSM‑10/20 (without auxiliary lens):

909.055 1x 5x / ø 20.0 10x / ø 20.0 15x / ø 15.0 20x / ø 10.0
909.051
2x 10x / ø 10.0 20x / ø 10.0 30x / ø 7.0 40x / ø 5.0
Soft rubber eye adapters
3x 15x / ø 7.0 30x / ø 7.0 45x / ø 5.0 60x / ø 3.5

4x 20x / ø 5.0 40x / ø 5.0 60x / ø 3.5 80x / ø 2.5

Item No. Description Price HUF Magnification Magnification / Field of view/mm Field of view camera/mm
909.089 Per pair objective Eyepiece 10x Eyepiece 20x 774.145 774.296 774.243

Stereo microscope with stepless zoom SSM‑E (without auxiliary lens):

909.089 from 1x 10x / ø 20.0 20x / ø 10.0 4.5 x 3.3 1 6.8 x 5.0 1 19.0 x 14.0 1
to 4x 40x / ø 5.0 80x / ø 2.5 1.2 x 0.8 1 1.4 x 1.0 1 2.7 x 2.0 1
from 1x
to 4x 5.6 x 4.1 2 18.0 x 12.0 2 C13.308.HOD.20250410
1.34 x 1.0 2 2.4 x 1.8 2

1 Camera intake in adapter bushing.
2 Camera intake in ocular.
