www.calidaddimensional.com CLINOMETERS

Clinometers Clinometer

 Measuring range: 4 x 90°.  Measuring range: 4 x 90°.
 Graduation: 1°.  Graduation: 1°.
 Dimensions: 100 x 15 x 100 mm.  Graduation vial: 2 - 5 mm/m.
 Flat base: 300 x 25 mm.
 With mounting holes.

857.302 Item No. Description Price
853.669 Clinometer

Item No. Description Price

857.302 Clinometer Clinometer
with removable base 100 mm
To determine inclinations accurately. Fine-
857.303 Clinometer tuning by means of a screw thread spindle,
with magnetic base 100 mm which, to ensure a quick tuning, can be
disconnected by pressing the button on the
Vernier clinometers micrometer.
 Measuring range: ± 180°.
Clinometers with two ground bases with  Read-out in degrees and minutes.
V‑groove, or two flat magnetic bases. Vial  Scale numbering black clockwise, red
holder with vernier and fine adjustment.
 Measuring range: 0 - 90°. counterclockwise.
 Vernier: 10'.  Graduation vial: 0.3 mm/m ≅ 1'.
 Graduation vial: 0.3 mm/m ≅ 1'.  Hardened and ground base, with V‑groove.
 Dimensions: 150 x 39 x 150 mm.  Base dimensions: 150 x 30 mm.
 Height: 124 mm.

857.301 857.300 Item No. Description Price C08.215.Calidad.20250912
857.310 Clinometer
Item No. Description Price
857.300 Bases with V‑groove
857.301 Flat magnetic bases

226
