www.calidaddimensional.com EXTERNAL MEASURING INSTRUMENTS

Peacock external measuring instruments

 Measuring range: 0 - 10 mm.
 Graduation: 0.01 mm.
 Accuracy: ± 0.02 mm.
 Measuring force: approx. 1.8 N.
 Non-interchangeable

measuring inserts.
 Ceramic measuring faces

(except 855.761: steel).

855.761 855.751

Item No. Measuring Measuring Throat Price
range/mm faces ø/mm depth/mm MXN

855.750 855.750 0 - 10 10 20
855.761 0 - 10 10 20
855.751 0 - 10 10 120

External measuring instruments

 Measuring range: 0 - 10 mm. 853.002 Types of inserts
 Graduation: 0.01 mm. 853.007 B Wood, rubber,
 Different types of inserts available,
ø10 soft leather
with hardened steel measuring
faces. ø25 C Soft rubber
 Throat depth: 50 mm.
D Rubber rings,
Item No. Type of insert Price ø5 round material
853.002 B
853.003 C E Paper,
853.004 D cardboard,
853.005 E ø16 fibrous plates
853.007 G R 1.5 G Metal

Thickness gauge for film measurement

 Measuring range: 0 - 1 mm.  Ceramic measuring faces.
 Graduation: 0.001 mm.  Delivery in a plastic case with a manufacturer
 Measuring force: approx. 3 N.
 Non-interchangeable measuring inserts. measuring report.
 Throat depth: 25 mm.
 Frame with insulating grip.

Item No. Measuring Meas. faces Price C04.247.Calidad.20250912
range/mm ø/mm MXN

907.859 0 - 1 10

119
