www.calidaddimensional.com STICK MICROMETERS
Stick micrometer sets
Measuring range: 50 - 5000 mm. 906.918
Measuring range micrometer:
906.911 - 906.917: 50 - 63 mm,
906.918: 150 - 175 mm,
906.919 - 906.923: 1000 - 1050 mm.
Graduation: 0.01 mm.
Accuracy:
906.911 - 906.918: ± (3 + n + L/50) µm, Item No. Measuring Number of Price
906.919 - 906.923: ± (7 + n + L/50) µm range/mm extensions
(n = number of extensions, 906.911 * 50 - 63 –
L = max. measuring length in mm). 906.912 50 - 100 2
Locking screw. 906.913 50 - 150 3
Spherical tungsten carbide measuring faces. 906.914 50 - 300 5
With insulating grips 906.915 50 - 500 6
(only 906.918 - 906.923). 906.916 50 - 1000 8
External diameter micrometer/extensions: 906.917 50 - 1500 10
906.911 - 906.917: 15.5 mm, 906.918 150 - 2000 9
906.918: 22 mm,
906.919 - 906.923: 28 mm. 906.919 * 1000 - 1050 –
Incl. setting gauge 906.920 1000 - 2000 5
(only 906.911 - 917: 50 mm, 906.921 1000 - 3000 6
906.918: 150 mm). 906.922 1000 - 4000 7
Delivery in a wooden case. 906.923 1000 - 5000 8
* Single instrument (without extensions).
Digital stick micrometer sets External diameter micrometer/extensions:
22 mm.
Measuring range: 150 - 2000 mm.
Measuring range micrometer: 150 - 175 mm. Incl. setting gauge: 150 mm.
Resolution: 0.001 mm. Delivery in a wooden case.
Locking screw.
Spherical tungsten carbide measuring faces.
With insulating grips
(only 906.797 - 906.799).
906.796
Item No. Measuring Number of Accuracy Price
range/mm extensions µm
906.798 906.796 * 150 - 175 – 6.5 C04.321.Calidad.20240712
906.797 150 - 1000 6 29
906.798 150 - 1500 8 41
906.799 150 - 2000 9 52
* Single instrument (without extensions).
