Schut Geometrical Metrology THERMOHYGROMETER / THERMAL IMAGER
Digital thermal imager
With this thermal imager one can easily measure and display (2.8" LCD color display) the thermal
image and temperature.
Measuring range: -20 to 250°C.
Field of view: 40 x 40°.
Accuracy: ± 2°C or ± 2%.
Thermal sensitivity: 0.1°C.
Thermal image resolution: 32 x 31 px.
Emissivity preset: 0.95,
selectable 0.10 - 1.00 per 0.01.
USB data output.
On/off switch.
Automatic switch-off.
Adjustable tolerance limits.
Backlight with 3 selectable levels of
brightness.
°C/°F/°K conversion.
4 selectable color palettes.
Alarm for adjustable upper und lower limit of
the temperature.
Frame rate: 9 Hz.
Spectral range: 8 - 14 µm.
Time stamp for images.
Storage for 25000 images.
Memory card: micro SDHC 8 GB, including
adapter for SD card reader.
Dimensions: 95 x 75 x 233 mm.
Weight (incl. batteries): 390 g.
Protection: IP54.
(When using data output: IP40.)
Delivery in a plastic carrying case with USB
cable and software.
Power supply: 4 batteries type AA.
Item No. Description Price EUR C18.306.EN.20260324
909.429 Thermal imager 429.00
Option: 0.70 Measuring instruments and systems 2025/2026
495.111 Battery type AA (4 needed)
