LMW plug gauges

Manufactured according DIN 2245, 2246 and 2247. Available from 0.5 - 160 mm; up to 70 mm
with Go and NoGo on one handle, over 70 mm in two parts. Prices are for H7 plug gauges with Go
and NoGo ends in hardened steel.

 H7 fit size in hardened steel.
 Available from 0.5 - 160 mm; up to 70 mm

with Go and NoGo on one handle, over
70 mm in two parts.
 Including wear allowance at the Go end.

Wear allowance
New gauges are supplemented with a wear al­

lowance on the Go end: z (plus) for plug gauges.
Accordingly, the size indicated on the handle is
not similar to the measured value of the new Go
end.

Example: plug gauge 20 H7 Measuring reports
New Go end:
For all gauges also measuring reports can be
size 20.000 mm ordered.
wear allowance (+ z) 0.003 mm  Manufacturer measuring report (German)
20.003 mm
manufacturing tolerance ± 0.002 mm per gauge. Stating of product specifications,
largest value measured 20.005 mm measured values after production, used
smallest value measured 20.001 mm traceable measuring devices, measuring
Also available: inaccuracy and measuring date. A favourable
– larger sizes, choice when your quality system does not
– without wear allowance, require traceable certificates.
– many other fit sizes, like H6, H8, P7, G7 etc.,  Traceable certificate (Dutch) with mea­suring
– hard-chrome plated plug gauges, reports of the ordered gauges. Besides stating
– tungsten carbide plug gauges, of the measured values the extra assurance of
– extended plug gauges, an external inspection.
– plug gauges with vent hole,
– plug gauges with easy-entry pilot.

Item No. Size Price Item No. Size Price Item No. Size Price Item No. Size Price Item No. Size Price

H7/mm EUR H7/mm EUR H7/mm EUR H7/mm EUR H7/mm EUR

832.101 1 74.00 832.119 10 50.00 832.133 24 72.00 832.151 42 106.00 832.179 70 183.00 C12.202.EN.20261007
832.102 1.5 68.00 832.120 11 52.00 832.134 25 74.00 832.153 44 113.00 832.181 72 191.00
832.103 59.00 832.121 12 53.00 832.135 26 75.00 832.154 45 116.00 832.184 75 199.00
832.104 2 59.00 832.122 13 55.00 832.136 27 77.00 832.155 46 119.00 832.187 78 209.00
832.105 2.5 52.00 832.123 14 56.00 832.137 28 79.00 832.156 47 122.00 832.189 80 212.00
832.106 47.00 832.124 15 58.00 832.139 30 80.00 832.157 48 125.00 832.191 82 227.00
832.107 3 47.00 832.125 16 59.00 832.141 32 87.00 832.159 50 129.00 832.194 85 234.00
832.108 3.5 47.00 832.126 17 61.00 832.142 33 90.00 832.161 52 135.00 832.197 88 244.00
832.109 43.00 832.127 18 63.00 832.143 34 92.00 832.164 55 141.00 832.199 90 250.00
832.110 4 43.00 832.128 19 65.00 832.144 35 93.00 832.167 58 151.00 832.201 92 257.00
832.111 4.5 43.00 832.129 20 65.00 832.145 36 95.00 832.169 60 158.00 832.204 95 264.00
832.113 45.00 832.130 21 68.00 832.146 37 97.00 832.171 62 164.00 832.207 98 274.00
832.115 5 47.00 832.131 22 69.00 832.147 38 100.00 832.174 65 169.00 832.209 100 280.00
832.117 5.5 48.00 832.132 23 71.00 832.149 40 103.00 832.177 68 180.00

6
7
8
9

Larger sizes available on request.
