Schut Geometrical Metrology PROTRACTORS
Bevel protractor with magnifier
Measuring range: 4 x 90°. Delivery in a plastic case with two blades
Vernier: 5', parallax-free. (150 and 300 mm) and an acute angle
Fine adjustment. attachment.
Hardened stainless steel construction.
Matt chrome-plated scale. Options: 855.812, 855.813 and 855.815.
Item No. Description Price EUR
855.801 Bevel protractor 231.00
with magnifier
Option: 37.10
859.179 Spare magnifier
Single blades
Item No. Blade Price
909.380 length/mm EUR
909.381 7.50
909.382 150 9.90
909.383 200 12.60
300 19.50
500
Universal bevel protractor
Universal bevel protractor with micrometer screw adjustment. One rotation of the screw corresponds
to an angular change of 1°. Retraction of the micrometer screw enables fast adjustment of the blade
and the scale.
Measuring range: 4 x 90°. Options: 855.812, 855.813 and 855.815.
Graduation: 1'.
Stainless steel construction, main
parts are hardened.
Delivery in a wooden case with
two blades (150 and 300 mm) and
a reference square for checking the
bevel protractor.
Single blades
Item No. Description Price EUR Item No. Blade length/mm Price EUR
855.811 Universal protractor 649.00 7.50
909.380 150 9.90 C08.205.EN.20250702
with magnifier 37.10 909.381 200
Option: 909.382 300 12.60
859.019 Spare magnifier 909.383 500 19.50
© 2025, Schut Geometrische Meettechniek bv 337 Measuring instruments and systems 2025/2026
