DIAL INDICATOR STANDS Schut for Precision

Bases for dial indicator stands

A solid base is essential for accurate measurements. The dial indicator arms can be mounted on a
strong magnetic or vacuum base.

5 mm
0-40 mm

908.969 908.971

402.196 910.513
908.967
908.965

908.968 908.976 908.977

Item No. Description Dimensions Magnetic force * Thread 910.511
l x w x h/mm N
Price EUR
908.971 V‑groove 60 x 50 x 55 800 (S) M8 x 1.25
908.970 V‑groove 74 x 50 x 55 1000 (S) M8 x 1.25 20.90
908.969 flat base 118 x 50 x 52 1500 (S) M8 x 1.25 29.50
908.967 V‑groove 36 x 30 x 35 400 (S) M5 x 0.8 89.00
908.976 flat base 30 x 30 x 30 170 (S) M5 x 0.8 23.00
908.968 flexform 75 x 46 x 55 400 (P) M8 x 1.25 25.30
908.965 cylinder 300 (P) M8 x 1.25 41.00
908.977 vacuum base ø 40 x 30 800 (S) M8 x 1.25 22.20
402.196 granite base ø 90 x 25 1000 (S) M8 x 1.25 34.70
910.511 V‑groove and fine adjustment 150 x 100 x 40 600 (S) M8 x 1.25 98.00
910.512 V‑groove and fine adjustment 60 x 50 x 55 M8 x 1.25 39.20
910.510 V‑groove and fine adjustment 74 x 50 x 55 M8 x 1.25 46.00
910.513 clamping base 58 x 50 x 55 M8 x 1.25 36.70
80 x 30 x 40 24.10

* S = switchable magnet; P = permanent magnetic force.

Fixing clamps for dial indicator stands

Item No. Fixing clamp ø/mm Price EUR
d1 d2

907.443 10 8 / 4 9.50 d1 d2 C06.323.EN.20260702
907.442 10 8 / 6 9.50
906.398 12 8 / 6 9.20
907.440 12 10 9.50
907.444 14 8 / 6 13.90
906.399 20 12 28.10
907.441 20 14 32.10
